How to create a chatbot on Google Dialogflow in 2025?

Google’s Dialogflow is one of the most powerful tools available for building chatbots & AI-driven conversational agents. Whether you're looking to enhance customer support, drive sales, or automate workflows, Dialogflow makes chatbot development accessible and efficient.

It is easy to use, can handles the complex conversation, available in many languages, easy integration with other tools, easy webhook integration (HTTP request events on specific action inside Dialogflow system).

In this guide, we’ll walk you through the step-by-step process of creating a chatbot using Dialogflow, covering all essential concepts and best practices.

What is Dialogflow?

Dialogflow is a Natural Language Understanding (NLU) platform that helps developers create conversational interfaces for applications, websites, and messaging platforms like WhatsApp, Facebook Messenger, and Slack. It is powered by Google Cloud’s machine learning capabilities, allowing it to understand user intent and generate intelligent responses.

Step 1: Setting Up Dialogflow

1.1 Create a Google Cloud Project

To use Dialogflow, you must first create a Google Cloud Project:

1. Visit Google Cloud Console.

2. Click on Create Project and enter a name for your project.

3. Enable Dialogflow API in the Google Cloud Console.

4. Set up billing (Dialogflow has a free tier, but certain features require a billing account).

1.2 Access Dialogflow Console

1. Go to the Dialogflow Console.

2. Sign in with your Google account.

3. Click on Create Agent and provide the agent’s name, default language, and time zone.

4. Choose Google Cloud Project linked to your Dialogflow agent.

Step 2: Creating Your Chatbot’s Structure

2.1 Understanding Intents

In Dialogflow, Intents represent the purpose of a user’s input. Each intent maps user queries to appropriate responses.

• Example: If a user asks, “What are your business hours?”, Dialogflow maps this to a predefined intent that provides the correct response.

2.2 Adding Intents

1. Go to the Intents tab in Dialogflow.

2. Click Create Intent and give it a name (e.g., 'greeting_intent').

3. Under Training Phrases, add user inputs like:

   • "Hello"

   • "Hey there"

   • "Good morning"

4. Under Responses, add chatbot replies:

   • "Hello! How can I assist you today?"

   • "Hi there! Need help with something?"

5. Click Save to train your chatbot.

Step 3: Enhancing Conversations with Entities

3.1 Understanding Entities

Entities help Dialogflow extract key information from user inputs. For example, if a user says “Book a flight from New York to Los Angeles”, New York and Los Angeles can be detected as location entities.

3.2 Creating Custom Entities

1. Navigate to Entities in Dialogflow.

2. Click Create Entity and provide a name (e.g., 'city_names').

3. Add synonyms for values:

   • New York → (NYC, New York City)

   • Los Angeles → (LA, L.A.)

4. Click Save and link the entity to relevant intents.

Step 4: Configuring Fulfillment for Dynamic Responses

4.1 Enabling Fulfillment

Fulfillment allows your chatbot to connect with databases, APIs, or other external systems to provide real-time responses.

1. In Dialogflow, navigate to Fulfillment.

2. Enable Webhook and provide a webhook URL.

3. Create a backend server (using Node.js, Python, or Firebase) to handle requests.

4.2 Writing Webhook Code (Example in Node.js)

const express = require("express");
const app = express();
app.use(express.json());

app.post("/webhook", (req, res) => {
    const intentName = req.body.queryResult.intent.displayName;
    let responseText = "";

    if (intentName === "book_flight") {
        responseText = "Sure! Where would you like to fly?";
    }
    res.json({ fulfillmentText: responseText });
});

app.listen(3000, () => console.log("Server is running"));

This webhook listens for book_flight intent and responds dynamically.

Step 5: Integrating Dialogflow Chatbot with Messaging Platforms

Once your chatbot is functional, you can integrate it with multiple platforms:

5.1 WhatsApp Business API Integration

To integrate your chatbot with WhatsApp, use a WhatsApp Business API provider like Heltar (or instead, opt for an easier version altogether i.e. our no code drag and drop chatbot builder)

1. Set up a WhatsApp Business API account.

2. Obtain API credentials from Heltar.

3. Connect Dialogflow to the WhatsApp API using webhooks.

4. Deploy and test your chatbot!

5.2 Facebook Messenger Integration

1. Go to Integrations in Dialogflow.

2. Enable Facebook Messenger.

3. Provide the Page Access Token from Facebook.

4. Set up webhooks for Messenger.

5. Deploy the chatbot and start engaging users.

Step 6: Testing and Deployment

6.1 Testing Your Chatbot

Dialogflow provides a built-in Testing Console where you can:

• Simulate conversations.

• Debug errors in responses.

• Improve chatbot performance using Training History.

6.2 Deploying Your Chatbot

1. Optimize training data and responses.

2. Set up Dialogflow on Google Cloud Functions for scalability.

3. Monitor chatbot interactions using Google Analytics.

4. Continuously update intents based on user feedback.

Google DialogFlow - CX vs ES

Google Dialogflow recently introduced Dialogflow CX (Customer Experience) – a powerful tool for creating advanced virtual agents. The older version of Dialogflow has been renamed to Dialogflow ES (Essentials). Dialogflow is now a common term to describe both the Dialogflow ES and CX. In this article, we can see the enhancements and limitations of Dialogflow CX vs ES.

Dialogflow CX provides a new way of designing virtual agents, taking a state machine approach to agent design. This gives a clear and explicit control over a conversation, a better end-user experience, and a better development workflow.

Creating a chatbot with Dialogflow is a straightforward process that involves defining intents, training responses, and integrating with external platforms. But Heltar also provides a no code drag-and-drop chatbot builder that can be used by literally anyone and everyone because of its intuitive UI. By leveraging Dialogflow’s AI capabilities, businesses can build chatbots that provide seamless, intelligent, and automated conversations for customer interactions.
