When working with WhatsApp Flows, you might run into the following error:

INVALID_ROUTING_MODEL

Following screens are missing in the routing model: (screenIDs).

This is a structural issue with your flow JSON. Let's break it down.

What Triggers INVALID_ROUTING_MODEL

This error occurs when one or more screen.ids defined in the screens array are not referenced anywhere in the routing_model. The WhatsApp API expects that every screen must be part of the routing logic — if a screen is unreachable, it’s considered invalid.

WhatsApp Flow JSON Structure Overview

A flow JSON has two key sections:

1. screens

An array of all screens used in the flow — each must have a unique id.

"screens": [
  {
    "id": "FIRST_SCREEN",
    "type": "FORM",
    ...
  }
]

2. routing_model

A mapping of screen transitions. It defines:

  • The start screen

  • Where each screen routes next, based on conditions or button selections

"routing_model": {
  "FIRST_SCREEN": [
    {
      "conditions": [...],
      "target": "NEXT_SCREEN"
    }
  ],
  "NEXT_SCREEN": []
}

Invalid Example

{
  "routing_model": {
    "ABC": []
  },
  "screens": [
    {
      "id": "FIRST_SCREEN",
      "type": "FORM"
    }
  ]
}​

  • FIRST_SCREEN is defined in screens.

  • But routing_model only includes ABC.

  • Result: FIRST_SCREEN is considered unreachable → error thrown.

 {
    "routing_model": {
    "FIRST_SCREEN": []
  },
  "screens": [
    {
      "id": "FIRST_SCREEN",
      "type": "FORM"
    }
  ]
}
  • Now FIRST_SCREEN is part of the routing model.
  • WhatsApp knows the flow starts or passes through this screen → error resolved.

Fixing the Error: Step-by-Step

1. Identify Missing Screens

Read the error:
INVALID_ROUTING_MODEL: Following screens are missing in the routing model: FIRST_SCREEN, END_SCREEN

2. Check for Typos

Ensure the screen ids in routing_model match exactly with the ones in screens.

3. Add Missing Screens to Routing

Include them in the routing_model like so:

"routing_model": {
  "FIRST_SCREEN": [
    {
      "target": "END_SCREEN"
    }
  ],
  "END_SCREEN": []
}

4. Optional: Remove Unused Screens

If any screen isn't meant to be used, remove it from the screens array to avoid unnecessary validation errors.
